€ 1.573,00
Beschikbaar via nabestelling
| Voltage Gain | 32 dB |
| Input Sensitivity | 2 V |
| Input Impedance | 20 kΩ |
| Slew Rate | +/-12 V/μs |
| Output Power (1 kHz – 0,1% THD) (1) | Stereo 8 Ω / 1000 + 1000 W Stereo 4 Ω / 1750 + 1750 W Stereo 2 Ω / 2500 + 2500 W (2) Bridge 8 Ω / 3500 W Bridge 4 Ω / 5000 W (2) |
| Average Current draw (3) | 6 A @ 230 V AC |
| Frequency Response | 20 Hz – 20 kHz (0/-1 dB) |
| Damping Factor (1 kHz @ 8 Ω) | 400 |
| Crosstalk | 65 dB |
| S/N Ratio (A-weighted) | 108 dB (A) |
| Mains | 220 – 240 V AC- 50/60 Hz |
| Dimensions (HxWxD) | 88 x 482 x 440 mm |
| Weight | 21 kg |
(1) Continuous burst tone 20 ms (0 dB) / 480 ms (-20 dB) in accordance with EIA RS-490 and IEC 60268-3(IHF A-202).
(2) Driving the amplifier at 2 Ω channel / 4 Ω bridge at full power mode in poor ventilation conditions may cause a thermal overload protection. 2 Ω power is time limited by mains circuit breaker.
(3) Heavy duty musical program.
